FS Series Square Vibrating Sieve
FS Series Square Vibrating Sieve
Detail
DESCRIPTION
This machine consists of screen box at material inlet and outlet, vibrator and shock absorber. There are 4-6 sets of flexible rubber shock absorber connected between base and screen box in up-down order. Centrifugal force is generated upon starting of the machine. Control shock absorber against amplitude eccentric device correspondingly for best performance and material screening process in throwing vibration and loose. It is the ideal choice for pharmaceutical, food, chemical, metallurgy and electronic industries.
TECHNICAL PARAMETERS
|
Model |
Production Capacity （kg/h） |
Sieve Mesh (mesh) |
Power (kw/h) |
Vibration Frequency (r/min) |
Excited Force (kN) |
Height of Top Exit |
Height of Middle Exit |
Height of Lower Exit |
Overall Dimension (L×W×H) |
Weight (kg) |
|
FS-0.5M2-X |
450 |
2-150 |
0.2×2 |
1400 |
0-2.5×2 |
800 |
680 |
500 |
1300×770 ×1060 |
220 |
|
FS-0.7M2-X |
650 |
2-150 |
0.2×2 |
1400 |
0-2.5×2 |
850 |
750 |
530 |
1700×680 ×1100 |
280 |
|
FS-0.8M2-X |
750 |
2-150 |
0.2×2 |
1400 |
0-2.5×2 |
850 |
750 |
530 |
1600×830 ×1150 |
320 |
|
FS-1.2M2-X |
1100 |
2-150 |
0.2×2 |
960 |
0-5×2 |
880 |
760 |
520 |
1900×980 ×1220 |
450 |
